1/10
YR Ultimate Brainpower 10T BL Motor & 35A Regler Set
+ Tornado
High Speed Cooling Fan (Gratis)
Das Set beinhaltet
einen sensorlosen 10T-Motor, einen 35A Fahrtenregler mit LiPo-Abschaltung sowie
ein Programmiergerät.
Features
* für 1/10 Onroad oder Offroad
* Kompatibel mit sensorlosen Motoren
* Zwei verschiedene Fahrmodi (Nur vorwärts oder vorwärts/rückwärts)
* Verschiedene Bremsmodi
* Verschiedene Startmodi
* LiPo-Unterspannungsschutz
* Überhitzungsschutz
* Wasser- und Staubdicht
* Einfach über ein Programmiergerät einzustellen
Technische
Daten Motor
* Turns: 10 T
* KV: 3900
Technische
Daten
* Belastbarkeit kontinuierlich: 35A
* Belastbarkeit kurzzeitig: 190A
* Nutzbare Brushless-Motoren: Über 9T (3650 brushless motor)
* Akku: 4-9 Zellen NiMh/NiCd oder 2-3 Zellen-Li-Po
* BEC Ausgang: 6V/1,5A
* Abmessungen: 31,5 x 27,5 x 24 mm (ohne Lüfter)
* Gewicht: 30g (ohne Kabel)
Der mitgelieferte
Programmer zum Einstellen des Fahrtenreglers.
Für eine grössere Darstellung klicken Sie auf das
Bild.
Yeah Racing Ultimate
Brainpower ESC 35A (Version 2) & 10T Sensorles
Yeah Racing (BM-0004V2) Ultimate Brainpower ESC 35A with fan is same as the
Yeah Racing (BM-0004) Ultimate Brainpower ESC 35A with fan plus new features,
please scroll down the description for full details
A FREE Yeah Racing (#YA-0180) Tornado
High Speed Cooling Fan for Motor Heat Sink (30x30x10mm) is included with the
purchase of Yeah Racing Ultimate Brainpower ESC 35A & 10T Sensorless Brushless
Motor Set
Motor Description:
# This is the Yeah Racing series 10T Sensorless Brushless Motor for RC cars
and trucks.
Feature:
# For: 1:10 / 1:12 RC
# Design: Sensorless-Based
# Operated with: Brushless ESC
Specification:
# Turns: 10 T
# KV: 3900
ESC Description:
# The Yeah Racing series brushless controls (Version 2) include ESC of 18A,
25A and 35A for RC cars and trucks.
Feature:
# The ESC is USB supported. The firmware of the ESC can be updated through an
USB adapter on the Advanced LCD Program Box (Optional device).(NEW)
# Especially designed for RC car, with excellent start-up, acceleration and
linearity features
# Compatible with sensorless brushless motor
# Use top quality of electronic components to enhance the current endurance
and capacity of the ESC.
# 2 running modes (Racing mode and Forward/Backward mode)
# 4 steps of maximum reverse force adjustment
# Proportional ABS brake function with 4 steps of 4th ¡V 11th maximum
brake force adjustment, 8 steps of drag-brake force adjustment and 4 steps of
initial brake force adjustment.
# 4 start modes (Also called ¡§Punch¡¨) from ¡§soft¡¨
to ¡§very aggressive¡¨.
# Multiple protection features: Low voltage cut-off protection for lithium or
nickel battery / Over-heat protection / Throttle signal loss protection / Motor
blocked protection.
# 8 steps of timing adjustment.
# Waterproof and dustproof.
# Easily program with only one button and compatible with pocket-sized program
card.
Specification:
# Cont. Current: 35A
# Burst Current: 190A
# Resistance: 0.015 ohm
# Suitable Car: 1/10 car
# Suitable Brushless Motor: > 9T (3650 brushless motor)
# Battery: 4-9 Cell Ni-xx (NiMh or NiCd) or 2-3 Cell Li-Po
# BEC Output: 6V/1.5A
# Motor Type: Sensorless Brushless Motor
# Dimension: 31.5 x 27.5 x 24 (mm) (The height of fan is excluded)
# Weight: 30g (Without wires)
Include:
# Ultimate Brainpower ESC 35A (1 Pc)
# 10T Sensorless Brushless Motor (1 Pc)
# Program card (1 Pc)
# Cable Tide (4 Pcs)
# Shrink Tube (3 Pcs)
|
